SZ - Ⅲ train bulk loader
SZ - Ⅲ bulk cement machine feeding mouth can make linear movement in the horizontal plane, is suitable for bulk train, large feed port bulk car and bulk ship loading. SZ - Ⅲ train bulk machine by the library side discharge gate, swing arm air delivery chute, walk and loading the first parts, car and have the characteristics of SZ - type I all bulk machine
1, the winding device 2, observation window 3, loose rope switch gear 4, wheel gear
5, the ventilator 6, double chute, 7, walking speed reducer 8, bulk head
9, feeding device 10, 24 kg/m rails (set) fixed way
Users should bring along their own dust collecting equipment, dust collecting air volume of about 4200 m3 / h. Electric cabinet order another, can be separately designed according to the requirements of control and system.
| 散裝頭 | 卷揚電動機 | 行走電動機 | 散裝頭震動電器 | 通風機 | |||||
| zui大行程 | zui大距離 | 功率 | 電壓 | 功率 | 電壓 | 功率 | 電壓 | 功率 | 電壓 |
| 2500mm | 6000mm | 2.2KW | 380V | 1.5KW | 385V | 0.06KW | 220V | 2.2KW | 380V |
